Re: [BaadAssGremlins] air shocks on amx & javelins
[Date Prev][Date Next][Thread Prev][Thread Next][Date Index][Thread Index]

Re: [BaadAssGremlins] air shocks on amx & javelins



Thanks for sharing this, Eddie. What a mess those shocks caused. I was considering air shocks, but instead got a set of helper springs from JC Whitney. They were under 50 bucks, bolted right on and gave me the two inches of lift I needed. I would have liked to change the springs, but I am not a mechanic so I have neither the tools or know how. Anyway, glad I did not go for the air shocks.

Charlie

In a message dated 6/25/2007 11:24:10 AM Eastern Daylight Time, eddiestakes@xxxxxxxxxxxxxxxxxxxx writes:

This comes up from time to time and while I personally have had problems
(dating back to 1977) with AMX and Javelin series with rear air shocks, here
is a photo below of the damage one caused. As mentioned before, usually the
upper shock tower on the driver side blows into the trunk, as while if you
keep it below 60psi you should be fine, however some insist on more and all
it takes is a small pothole, dip in road, possum or other critter, even
speed bump, and below is what happens.

The shock tower on back of a 68-69 and 70-74 was not intended to have that
upwards pressure and it flimsy to begin with and anyone who has ever gotten
under one of these knows not much to it, and you can see how AMC grafted the
plate on driver side for the shock tower to basically sheetmetal.

So when you are considering air shocks because you want big ass tires, or a
lifted rear or something like that on your AMX or Javelin, consider below
photo. I have had abuot 4 of them do this to me thru years and really
difficult finding any welding shop willing to tackle, much less warranty the
work if you need the 'air shock patch'.

Again, your results may vary, like my old 68 AMX The Red Death had Gabriel
air shocks on it for over 20 years and 170,000 miles with zero problems.

This is off a auction on ebay for a 74 AMX:


Charlie

"Cool Factor X"
